27" Elo 2794L Einbau Touch Monitor
| Model | 2794L |
|---|---|
| Bezel color | Black |
| Active Display Area | 597.6 x 336.15 mm / 23.53 x 13.23 inches |
| Dimensions | IntelliTouch: 633.2 x 374.4 x 41.8 mm / 24.93 x 14.74 x 1.65 inches IntelliTouch Plus: 633.2 x 374.4 x 41.8 mm / 24.93 x 14.74 x 1.65 inches ITouch: 644.2 x 388.4 x 39.6 mm / 25.36 x 15.29 x 1.56 inches Projected Capacitive: 644.2 x 388.4 x 39.6 mm / 25.36 x 15.29 x 1.56 inches See dimensional drawings for details |
| LCD Technology | Active matrix TFT LCD |
| Diagonal Size | 27" |
| On-Screen Display (OSD) |
Accessible through switches on the unit’s tethered OSD Control box. Controls: Menu, Up, Down, Select, Power Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese Lockouts: OSD, Power |
| Native Resolution | 1920x1080 |
| Aspect Ratio | 16:9 |
| Preset Video Timings | 640x480 60Hz 720x400 70Hz 800x500, 60Hz 800x600 56, 60Hz 1024x768 60Hz 1280x800 60Hz 1280x1024 60Hz 1366x768 60Hz, 60Hz RB 1440x900 60Hz, 60Hz RB 1680x1050 60Hz, 60Hz RB 1920x1080 50, 60Hz |
| Number of Colors | 16.7 million |
| Brightness (typical) | LCD panel: 300 nits iTouch: 270 nits IntelliTouch: 270 nits IntelliTouch Plus: 270 nits Projected Capacitive (PCAP): 270 nits |
| Response Time (Tr + Tf) (typical) | 12 msec |
| Viewing Angle (typical) | 89°/89° or 178°/178° |
| Contrast Ratio (typical) | 3000:1 |
Video| Video | Analog VGA on Female DB-15 connector DisplayPort V1.1a - Supports later versions of Display Port video input Input Video Horizontal Sync frequency range: 30 - 82KHz Input Video Vertical Sync (frame rate) frequency range: 50-75Hz |
|---|---|
| Audio | N/A |
Power| Power |
External DC - Optional power brick (sold separately) Monitor input power connector: Coaxial power jack (2.1mm pin outer diameter, 5.5mm barrel inner diameter) Monitor input power signal specifications: 12VDC +/- 5% Adapter input connector: IEC 60320 C14 Adapter input voltage range: 100-240VAC, 50/60Hz Power Consumption (Typical): ON (monitor + adapter at 230V/50Hz): 20WSLEEP (monitor + adapter at 230V/50Hz): 1.5W OFF (monitor + adapter at 230V/50Hz): 0.5W ` |
|---|
Dimensions| Shipping box Dimensions | 782 (L) x 530 (W) x 200 (H) mm / 30.79 (L) x 20.87 (W) x 7.87 (H) inches |
|---|
Weight| Weight | Unpackaged: 7.3 Kg (16.1 lb) Packaged: 10.1 Kg (22.27 lb) |
|---|
Environmental| Temperature | Operating: 0°C to 40°C (32°F to 104°F) Storage: -20°C to 60°C (-4°F to 140°F) |
|---|---|
| Humidity (non-condensing) |
Operating: 20% - 80% Storage: 10% - 95% |
Other| Form Factor | Open-Frame |
|---|---|
| MTBF | 50,000 hours demonstrated |
| Mounting Options |
|
| Box contents |
|
