19" Elo 1991L Einbau Touch Monitor

Menge / Ausführung

Gesamtsumme:

Stückpreis:

Grundpreis:

Lagerbestand

Beschreibung

Informationen

Zubehör

Frage zum Produkt

Model	1991L
Bezel color	Black
Active Display Area	376.32 x 301.06 mm / 14.8 x 11.85 inches
Dimensions	IntelliTouch: 414.7 x 342.7 x 50 mm / 16.33 x 13.50 x 1.97 inches SecureTouch: 414.7 x 342.7 x 50 mm / 16.33 x 13.50 x 1.97 inches AccuTouch: 414.7 x 342.7 x 50 mm / 16.33 x 13.50 x 1.97 inches Projected Capacitive: 420.1 x 348.1 x 40.7 mm / 16.54 x 13.70 x 1.60 inches See dimensional drawings for details
LCD Technology	Active matrix TFT LCD
Diagonal Size	19"
On-Screen Display (OSD)	Accessible through switches on the unit’s tethered OSD Control box. Controls: Menu, Up, Down, Select, Power Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Through Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese Lockouts: OSD, Power
Native Resolution	1280x1024
Aspect Ratio	5:4
Preset Video Timings	640x480 60Hz 720x400 70Hz 800x500, 60Hz 800x600 56, 60Hz 1024x768 60Hz 1280x800 60Hz 1280x1024 60Hz
Number of Colors	16.7 million
Brightness (typical)	LCD panel: 250 nits AccouTouch: 200 nits SecureTouch: 200 nits IntelliTouch: 225 nits Projected Capacitive (PCAP): 225 nits
Response Time (Tr + Tf) (typical)	14 msec
Viewing Angle (typical)	89°/89° or 178°/178°
Contrast Ratio (typical)	1000:1

Video

Video	Analog VGA on Female DB-15 connector DisplayPort V1.1a - Supports later versions of Display Port video input Input Video Horizontal Sync frequency range: 30 - 82KHz Input Video Vertical Sync (frame rate) frequency range: 50-75Hz
Audio	N/A

Power

Power	External DC - Optional power brick (sold separately) Monitor input power connector: Coaxial power jack (2.1mm pin outer diameter, 5.5mm barrel inner diameter) Monitor input power signal specifications: 12VDC +/- 5% Adapter input connector: IEC 60320 C14 Adapter input voltage range: 100-240VAC, 50/60Hz Power Consumption (Typical): ON (monitor + adapter at 230V/50Hz): 16W SLEEP (monitor + adapter at 230V/50Hz): 1.5W OFF (monitor + adapter at 230V/50Hz): 0.5W `

External DC - Optional power brick (sold separately)

Monitor input power connector: Coaxial power jack (2.1mm pin outer diameter, 5.5mm barrel inner diameter)

Monitor input power signal specifications: 12VDC +/- 5%

Adapter input connector: IEC 60320 C14

Adapter input voltage range: 100-240VAC, 50/60Hz

Power Consumption (Typical):

ON (monitor + adapter at 230V/50Hz): 16W
SLEEP (monitor + adapter at 230V/50Hz): 1.5W
OFF (monitor + adapter at 230V/50Hz): 0.5W `

Dimensions

Shipping box Dimensions	526 (L) x 450 (W) x 190 (H) mm / 20.71 (L) x 17.72 (W) x 7.48 (H) inches

Weight

Weight	Unpackaged: 4.6 Kg (10.14 lb) Packaged: 6.9 Kg (15.21 lb)

Environmental

Temperature	Operating: 0°C to 40°C (32°F to 104°F) Storage: -20°C to 60°C (-4°F to 140°F)
Humidity (non-condensing)	Operating: 20% - 80% Storage: 10% - 95%

Other

Form Factor	Open-Frame
MTBF	50,000 hours demonstrated
Mounting Options	75 mm VESA mount (PCAP Models) 75 mm and 100mm VESA mount (IT/AT/ST Models) Rear mount (PCAP Models) 2 Hole mounting interface on all four sides. Front mount with optional bezel kit (IT/AT/ST Models see Part Numbers for details) Rack mount with optional kit (IT/AT/ST Models see Part Numbers for details) Flush mount with included brackets (PCAP Models see dimensional drawings for details) See dimensional drawings for details
Box contents	Touch USB Cable VGA Cable Remote OSD Flush Mount Brackets w/Screws (Pcap Models) "L" (Side Mount )Brackets w/Screws ( IT/ST/AT Models) User Manual CD Quick Install Guide
